WPC Door Frame Extrusion Machine use PVC and Wood Powder Mixed Material, It can produce hollow type and solid type door frame profile. The surface could be with ASA co-extrusion or hot stamping/ Laminating.
WPC PVC Door Frame Profile Extrusion Line Machine List
| Auto feeder | 1 set |
| SJMS65/132 conical double screw extruder | 1 set |
| Die and mold | |
| Calibrating Table | 1 set |
| Haul  off machine | 1 set |
| Cutting machine | 1 set |
| Product stacker | 1 set |
Detailed Description of the WPC PVC Door Frame Extrusion Machine
Feeding machine
The Material should be mixed by mixing machine according to our formula.
the mixed material shall be put into a auto feeding tank, and then feeded to the extruder.
Extruder
We equip the SJMS65/132 conical double screw extruder for WPC solid door frame making.
the extrusion capacity can be 150-240 kg per hour.
the main motor power is 37kw with ABB inverter.
the extruder equipped with Vacuum exhuasting system for moisture.
Formulation of WPC PVC Door Frame Machine
| Item | Material name | Mixing Ratio |
| 01 | PVC resin | 100 kgs |
| 02 | wood powder | 25-40 kgs |
| 03 | CaCo3 | 40 kgs |
| 04 | Chemical additives | around 15 kgs |
